PowerPlex® Fusion 6C System
6-Color Co-Amplification and Detection of 27 Loci
- Amplify all loci in the expanded CODIS core loci (including 23 autosomal STRs, 3 Y-STRs and Amelogenin)
- Direct-amplification protocols and rapid cycling capabilities reduce processing time for all samples
- High inhibitor tolerance and sensitivity for casework
Catalog Number:
Size
Catalog Number: DC2705
Catalog Number: DC2720
Catalog Number: DC2780
Highest Inter-Database Compatibility and Discrimination
The PowerPlex® Fusion 6C System provides all of the materials needed for co-amplification and fluorescent detection of 27 loci, including the CODIS core loci and European Standard Set (ESS) loci, and Amelogenin and DYS391 for gender determination. The Penta D, Penta E, TPOX, D22S1045 and SE33 loci are also included. Finally, two rapidly mutating Y-STR loci, DYS570 and DYS576, are included in the multiplex. This comprehensive set supports compatibility with present databases across multiple regions and encompasses an expanded set of loci to address future growth. The PowerPlex® Fusion 6C System delivers more information and high success rates from demanding forensic, paternity and relationship-testing cases.
Promega forensic products are manufactured in alignment with the ISO 18385 standard. This standard ensures minimal risk of human DNA contamination for products used to collect, store and analyze biological materials for forensic purposes. Learn more.
High Discriminatory Power
The Probability of Identity value achieved with the PowerPlex® Fusion loci set is exceptional. By combining US CODIS and ESS loci, the system offers significant gains in discriminatory power and helps ensure fewer adventitious matches are obtained.
A probability of identity value (PI) is defined as the probability that two individuals selected at random will have an identical genotype at the tested locus.
| STR Kit | Number of Loci | PI* (N = 1036) |
|---|---|---|
| GlobalFiler™ STR Kit | 23 | 1.63 × 10–27 |
| Investigator® 24plex Kit | 23 | 1.63 × 10–27 |
| PowerPlex® Fusion System | 24 | 1.38 × 10–28 |
| PowerPlex® Fusion 6C System | 27 | 9.09× 10–31 |
*Note: PI values do not include Amelogenin or Y-STRs.
Reference: Steffen, C.R. et al. (2017) FSI Genetics Corrigendum to ‘U.S. Population Data for 29 Autosomal STR Loci’. doi: https://doi.org/10.1016/j.fsigen.2017.08.011
Superior Sensitivity
The PowerPlex® Fusion 6C System reliability produces complete STR profiles from as little as 125pg of human DNA and usable, partial profiles from DNA amounts lower than 125pg.
PowerPlex® Fusion 6C System
GlobalFiler® PCR Amplification Kit
Enhanced Inhibitor Tolerance
The PowerPlex® Fusion 6C System can successfully meet the challenges of inhibitor-laden samples, increasing your success rate and minimizing the need to re-amplify samples.
Direct-Amplification Compatibility for Most Sample Types
The PowerPlex® Fusion 6C System enables direct amplification with 12.5μl reactions from numerous sample types, including FTA® card punches, pretreated nonFTA cards (data not shown) and commonly used swabs. Laboratories can streamline their workflow while stretching their budget.
Direct amplification of two 1.2mm punches from a buccal sample on an FTA® card using the recommended protocol for 12.5μl reactions.
FTA® Card Punches
A buccal swab was pretreated with SwabSolution™ Reagent as recommended in the SwabSolution™ Kit Technical Manual. Following incubation, 2μl of extract was added to the PCR amplification mix using the recommended protocol for 12.5μl reactions.
Swab
Rapid Processing Solutions for PowerPlex® Systems
The 5X AmpSolution™ Reagent, SwabSolution™ Kit and PunchSolution™ Kit allow fast and simple processing of swabs and punches for analysis with various PowerPlex® Systems, including the PowerPlex® 21, 18D, 16HS, ESX, ESI, CS7 and Y23 Systems. These products are intended for preparation of single-source reference, database and paternity samples where sample purification is unnecessary.
Which Product is Right for Me?
Take me to the Product SelectorProtocols
Complete Protocol
Quick Protocols
Specifications
Catalog Number:
What's in the box?
| Item | Part # | Size | Concentration | Available Separately |
|---|---|---|---|---|
|
2800M Control DNA |
DD710A | 1 × 25μl | 10ng/μl | View Product |
PowerPlex® Fusion 6C Allelic Ladder Mix |
DG417B | 1 × 25μl | ||
WEN Internal Lane Standard 500 |
DG500A | 1 × 200μl | View Product | |
PowerPlex® Fusion 6C 5X Primer Pair Mix |
DK419B | 1 × 250μl | ||
PowerPlex® Fusion 6C 5X Master Mix |
DP114A | 1 × 250μl | ||
|
Water, Amplification Grade |
DW099A | 1 × 1,250μl | View Product |
SDS
Search for SDSCertificate of Analysis
Use Restrictions
Not For Medical Diagnostic Use.Storage Conditions
U.S. Pat. No. 9,139,868, European Pat. No. 2972229, Japanese Pat. No. 6367307 and other patents pending.
TMR-6C, CXR-6C, TOM-6C and WEN-6C dyes are proprietary.
What's in the box?
| Item | Part # | Size | Concentration | Available Separately |
|---|---|---|---|---|
|
2800M Control DNA |
DD710A | 1 × 25μl | 10ng/μl | View Product |
PowerPlex® Fusion 6C Allelic Ladder Mix |
DG417B | 4 × 25μl | ||
WEN Internal Lane Standard 500 |
DG500A | 2 × 200μl | View Product | |
PowerPlex® Fusion 6C 5X Primer Pair Mix |
DK419B | 4 × 250μl | ||
PowerPlex® Fusion 6C 5X Master Mix |
DP114A | 4 × 250μl | ||
|
Water, Amplification Grade |
DW099A | 5 × 1,250μl | View Product |
SDS
Search for SDSCertificate of Analysis
Use Restrictions
Not For Medical Diagnostic Use.Storage Conditions
U.S. Pat. No. 9,139,868, European Pat. No. 2972229, Japanese Pat. No. 6367307 and other patents pending.
TMR-6C, CXR-6C, TOM-6C and WEN-6C dyes are proprietary.
What's in the box?
| Item | Part # | Size | Concentration | Available Separately |
|---|---|---|---|---|
|
2800M Control DNA |
DD710A | 1 × 25μl | 10ng/μl | View Product |
PowerPlex® Fusion 6C Allelic Ladder Mix |
DG417C | 4 × 100μl | ||
WEN Internal Lane Standard 500 |
DG500A | 5 × 200μl | View Product | |
PowerPlex® Fusion 6C 5X Primer Pair Mix |
DK419C | 4 × 1,000μl | ||
PowerPlex® Fusion 6C 5X Master Mix |
DP114B | 4 × 1,000μl | ||
|
Water, Amplification Grade |
DW099A | 10 × 1,250μl | View Product |
SDS
Search for SDSCertificate of Analysis
Use Restrictions
Not For Medical Diagnostic Use.Storage Conditions
U.S. Pat. No. 9,139,868, European Pat. No. 2972229, Japanese Pat. No. 6367307 and other patents pending.
TMR-6C, CXR-6C, TOM-6C and WEN-6C dyes are proprietary.
